Round Enameled Copper Wire
| ♦Description: | This is a magnet wire with the copper conductor in round shape. It's an essential part of winding for electric appliances. This series is Xiandeng's top-selling goods and the corona resistant magnet wire listed below is the new entrant. | |||||||
| ♦Specifications: | As a professional magnet wire manufacturer, we offer a large span of wire gauge from 0.08mm to 6mm & a thermal class of 130~240℃. | |||||||
| ♦Application: | This series is used in a variety of industries of Industry motor, Auto motor, Transformer, Household appliances, Instruments, and meters, etc. | |||||||
| ♦Properties: | (a) good electrical properties like few pinholes under high voltage, (b) resistance to mechanical stress, (c) excellent heat, chemical, solvent resistance, (d) abrasion resistance, (e) long thermal life and (f) long corona resistant life for model EI/AIWCR/200, etc. | |||||||
| Product Model | Insulation Type | Thermal Class | Wire Gauge | AWG | National Standard | IECStandard | NEMA Standard | Application |
| PEW/130 | Polyester | 130℃ (B) | 0.08-6.00mm | (4-40) | GB/T 6109.7 | IEC 60317-34 | - | Household appliance, Transformer, Industry motor |
| PEW/155 | Polyester | 155℃ (F) | 0.08-6.00mm | (4-40) | GB/T 6109.2 | IEC 60317-3 | MW 5-C | Household appliance, Transformer, Generator, Power tool |
| EIW/180 | Polyester-imide | 180℃ (H) | 0.08-6.00mm | (4-40) | GB/T 6109.5 | IEC 60317-8 | MW 30-C MW 72-C | |
| EI/AIW/200 | Polyester or Polyester-imide overcoated polyamide-imide | 200℃ (C) | 0.08-6.00mm | (4-40) | GB/T 6109.20 | IEC 60317-13 | MW 35-C MW 73-C | Household appliance, Transformer, Auto motor,Power tool |
| AIW/220 | Polyamide-imide | 220℃ (C) | 0.80-2.50mm | (10.5-40) | - | IEC 60317-57 | MW 81-C | New energy auto motor, |
| PIW/220 | Polyamide | 220℃ (C) | 0.80-2.50mm | (10.5-40) | GB/T 6109.6 | IEC 60317-7 | - | |
| PIW/240 | Polyamide | 240℃ (C) | 0.80-2.50mm | (10.5-40) | GB/T 6109.22 | IEC 60317-46 | MW 16-C | |
| UEW/155 | Polyurethane | 155℃ (F) | 0.08-2.00mm | (12.5-40) | GB/T 6109.10 | IEC 60317-20 | MW 79-C | Micro-motor, Instruments and meters |
| UEW/180 | Polyurethane | 180℃ (H) | 0.08-2.00mm | (12.5-40) | GB/T 6109.23 | IEC 60317-51 | MW 82-C | |
| EI/AIWCR/200 | Corana-resistant Polyester-imide overcoated polyamide-imide | 200℃ (C) | 0.30-2.00mm | (13.5-29) | GB/T 21707 | - | - | Variable frequency motor |
| SEIW/180 | Solderable Polyester-imide | 180℃ (H) | 0.10-1.50mm | (15-38) | GB T 6109.13 | IEC 60317-23 | MW 77-C | Auto motor, Instruments and meters |
